Stainless Steel Plate

Stainless Steel Plate is perfect for many kinds of applications. You can order custom-cut lengths with specific dimensions to meet your requirement. Our prices are competitive, and we offer a wide variety of sizes and thicknesses.

keyword:

dimensions competitive

Category:

Stainless steel coils and plates

Feedback

Stainless Steel Plate

Product Specification and Size (For Reference)

	ASTM	JIS	AISI	EN	Mill's Standard
Grade	S30400 S30403 S31603 S43000	SUS304 - - SUS430	304 304L 316L 430	1.4301 1.4307 1.4404 1.4016	202 204Cu3

Other specifications are also available up to request

Available Size

Thickness	Width	Length	Surface Finish
15~85 mm	914, 1219, 1524 mm	3048, 6069 mm 10 M	Black
3~8 mm	20~1524 mm	Container Loading: Max. 10M Bulk: as request	No.1
8 up ~ 60 mm	30~1524 mm	Max. 6096 mm	No.1

Application

INOX. stainless steel plate is an extremely popular mills processed material that offers good corrosion resistance for numerous types of applications. Stainless steel plate is widely used in internal equipment, walls, pressure vessels and marine applications. 430 stainless steel plate is suitable for dry or internal environment equipment. 304 stainless steel plate is suitable for outdoor walls or windows. 316 stainless steel plate is suitable for the pressure vessel of industrial and marine applications.

Dimension and Shape Tolerance

Thickness Tolerance: According to 1/2 JIS G4304
Thickness	Tolerance
8.0 mm < T ≦ 10.0 mm	±0.32 mm
10.0 mm < T ≦ 25.0 mm	±0.34 mm
25.0 mm < T ≦ 85.0 mm	±0.40 mm

Length Tolerance: According to 1/2 JIS G4304
Thickness	Tolerance
T ≦ 10.0 mm	-0 / +60 mm
10.0 mm < T ≦ 85.0 mm	-0 / +65 mm

Width Tolerance: Max. Aim ±10 mm

Edge Crack: Max. 5 mm per side

Chemical Composition & Mechanical Property

Chemical Composition (For Reference)

JIS Specification
	Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other
Spec. JIS G4304 G4305 G4312	SUS304	8.0~10.5	18.0~20.0	0.08	1	2	0.045	0.03	-	-	-
	SUS304L	9.0~13.0	18.0~20.0	0.03	1	2	0.045	0.03	-	-	-
	SUS316L	12.0~15.0	16.0~18.0	0.03	1	2	0.045	0.03	2.0~3.0	-	-
	SUS430	0.6	16.0~18.0	0.12	0.75	1	0.04	0.03	-	-	-

ASTM Specification
	Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other
Spec. ASTM A240	S30400	8.0~10.5	17.5~19.5	0.07	0.75	2	0.045	0.03	-	-	N: 0.1 Max.
	S30403	8.0~12.0	17.5~19.5	0.03	0.75	2	0.045	0.03	-	-	N: 0.1 Max.
	S31603	10.0~14.0	16.0~18.0	0.03	0.75	2	0.045	0.03	2.0~3.0	-	N: 0.1 Max.
	S43000	0.75	16.0~18.0	0.12	1	1	0.04	0.03	-	-	-

JIS Specification
	Steel Grade	N/mm² MIN. Tensile Stress	N/mm² MIN. Proof Stress	% MIN. Elongation	HRB MAX. Hardness	Bendability: Bending Angle	Bendability: Inside Radius
Spec. ASTM A240	SUS304	520	205	40	90	No Require	-
	SUS304L	480	175	40	90	No Require	-
	SUS316L	480	175	40	90	No Require	-
	SUS430	420	205	22	88	180°	1.0 time the thickness

ASTM Specification
	Steel Grade	N/mm² MIN. Tensile Stress	N/mm² MIN. Proof Stress	% MIN. Elongation	HRB MAX. Hardness	HBW MAX. Hardness	Bendability: Bending Angle	Bendability: Inside Radius
Spec. ASTM A240	S30400	515	205	40	92	201	No Require	-
	S30403	485	170	40	92	201	No Require	-
	S31603	485	170	40	95	217	No Require	-
	S43000	450	205	22A	89	183	180°	-
